Features
Discover the innovative features that set our products apart, designed to streamline your workflow, enhance efficiency, and provide a seamless user experience tailored to your specific needs.
01
Subsea data access without recovery
- Enables access to data from deployed subsea instruments when recovery to the surface is impractical.
- Supports real-time communication, depending on the connected instrument.
- Helps reduce field time by supporting faster data review and operational decision-making.
02
Transparent cable-replacement link
- Creates a transparent RS232 optical link through water.
- Provides cable-like access to compatible subsea instruments without a permanent physical data cable.
- Offers a cost-effective alternative to ROV-mateable connectors and cables.
03
Designed for work-class ROV operation
- Supports data transfer through the ROV umbilical cable.
- Simplifies subsea deployment and operation using the ROV-side modem.
- Transfers data wirelessly once the ROV-side unit is aligned with the subsea unit.
04
Compatible with RS232 instruments
- Compatible with instruments using an RS232 serial interface.
- RS485 compatibility available as an option.
05
Deployment-ready accessories
- ROV cable, test cable and ROV handle options available.
- External battery and subsea cable options available for supported configurations.
- Manuals supplied to support setup, testing and field operation.
Specifications
Explore the advanced capabilities of our instruments and systems through their technical specifications.
| Interface | RS232, with RS485 compatibility optional |
|---|---|
| Protocol | Transparent link, with cable replacement functionality |
| Temperature | 115,200 baud |
| Transmission type | Digitally coded telemetry with error detection |
| Data throughput* | 10.2 kBytes/s |
| Light band | Cyan visible light |
| Operating range | Typically 1 m to 2 m, depending on environment |
| Maximum depth | 3,500 m |
| Temperature | Operating: -5°C to 40°C | Storage: -40°C to 65°C |
| External power | ROV unit: 9 VDC to 36 VDC | Subsea unit: 6.5 VDC to 32 VDC |
| Serial wake-up | ROV unit as standard, optional on subsea unit |
| Optical wake-up | ROV unit | Subsea unit |
| Dimensions | 285 mm length x 72 mm maximum diameter | 60 mm main housing diameter |
| Weight | 4 kg in air | 3 kg in water |
| Material | 316 stainless steel with Perspex window |
FAQs
What is the AQUAmodem® Op2 used for?
The AQUAmodem® Op2 is used for wireless subsea data access, allowing operators to communicate with compatible underwater instruments without recovering them to the surface.
How does the AQUAmodem® Op2 work?
The system uses a pair of optical modems to create a transparent RS232 link through water. One modem remains connected to the subsea instrument, while the ROV positions the second modem to establish the optical link.
Can the AQUAmodem® Op2 download data from subsea instruments?
Yes. The Op2 supports short-range interrogation, control and data download from compatible subsea instruments.
Does the AQUAmodem® Op2 provide real-time communication?
Yes, the Op2 can support real-time remote access to subsea instruments, depending on the connected instrument and deployment setup.
What instruments is the AQUAmodem® Op2 compatible with?
The Op2 is compatible with instruments using RS232 serial interfaces, including Aquatec’s HYDROlog® and AQUAlogger® ranges. RS485 compatibility is available as an option.
What is the depth rating of the AQUAmodem® Op2?
The AQUAmodem® Op2 is depth rated to 3,500 m.
What is the operating range of the AQUAmodem® Op2?
The typical operating range is 1 m to 2 m, depending on environmental conditions.
Is the AQUAmodem® Op2 suitable for ROV operations?
Yes. The Op2 is suitable for work-class ROVs and can support subsea data transfer through the ROV umbilical cable.
